S Couplers KK130
Fittings and Tubing ? Fittings for General Purposes(S Couplers/Multi-connectors)
-
?Cv factor: Increased by 34%＊
?Plug insertion force: Reduced by 22% (20 N)＊
?Lightweight: Weight reduced by 14% (12 g)＊
?。?Compared to the existing model
| Series | Applicable tubing O.D. | Connection thread (R, NPT) |
|---|---|---|
| KK130 | φ6，φ8，φ10，φ12 φ1/4''，φ5/16''，φ3/8''，φ1/2'' | 1/8，1/4，3/8，1/2 |
