Pneumatic Solenoid Valves
- Energy Saving
- By Industry ⁄ Process
- Applications
Application Example
5-Port Solenoid Valve/Plug-in Type SY3000/5000/7000
Directional Control Valves ? Pilot Operated 4/5 Port Solenoid Valves
-
?Due to the flow increase, the valve size can be reduced!
Saves energy and space
?Power consumption: 0.1 W (With power saving circuit)/0.35 W (Standard)
?Plug-in sub-plate has been newly added!
?Plug-in metal base (IP40)/Plug-in connector connecting base (IP67)
?Manifold type no.: SS5Y3, SS5Y5, SS5Y7
?Can be connected to F.R.L. units (AC-D series) (-X990)
?Supports Interface regulators
＊The EX250/500 series is to be discontinued. When designing new
equipment and facilities, consider using another series (EX260/EX600)
instead.
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions
Selection/Technical Data Quick Selection Table Green Procurement (RoHS)
Selection/Technical Data Quick Selection Table Green Procurement (RoHS)
| Series | Flow rate characteristics 4/2→5/3（A/B→EA/EB） C［dm3/（s?bar）］ | Flow rate characteristics 4/2→5/3（A/B→EA/EB） b | Applicable cylinder size | Power consumption (W) |
|---|---|---|---|---|
| SY3000 | 1.6 | 0.19 | φ50 | 0.35(Standard) 0.1(With power saving circuit) |
| SY5000 | 3.6 | 0.17 | φ63 | 0.35(Standard) 0.1(With power saving circuit) |
| SY7000 | 5.9 | 0.20 | φ80 | 0.35(Standard) 0.1(With power saving circuit) |
5-Port Solenoid Valve SY3000/5000/7000/9000
Directional Control Valves ? Pilot Operated 4/5 Port Solenoid Valves
-
?The combined mounting of a 3-port valve and a 5-port valve is possible.
?Power consumption: 0.1 W (With power saving circuit)
?A wide variety of manifold options are available, such as the aluminum
body manifold, DIN rail, and stacking type manifold.
?Manifold type no.: SS5Y3, SS5Y5, SS5Y7, SS5Y9
?Supports Interface regulators
＊The EX510 series is to be discontinued. When designing new equipment
and facilities, consider using another series (EX260/EX600) instead.
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Flow rate characteristics 4/2→5/3（A/B→EA/EB） C［dm3/（s?bar）］ | Flow rate characteristics 4/2→5/3（A/B→EA/EB） b | Flow rate characteristics 4/2→5/3（A/B→EA/EB） Cv | Applicable cylinder size | Power consumption (W) |
|---|---|---|---|---|---|
| SY3000 | 1.1 | 0.30 | 0.26 | φ40 | 0.35(Standard) 0.1(With power saving circuit) |
| SY5000 | 2.8 | 0.29 | 0.66 | φ63 | 0.35(Standard) 0.1(With power saving circuit) |
| SY7000 | 4.5 | 0.27 | 1.1 | φ80 | 0.35(Standard) 0.1(With power saving circuit) |
| SY9000 | 10 | 0.29 | 2.5 | φ100 | 0.35(Standard) 0.1(With power saving circuit) |
| SY300 | 1.1 | 0.30 | 0.26 | φ40 | 0.35(Standard) 0.1(With power saving circuit) |
| SY500 | 2.8 | 0.29 | 0.66 | φ63 | 0.35(Standard) 0.1(With power saving circuit) |
ISO 13849-1 Certified/3-Port Solenoid Valve/Residual Pressure Release Valve with Detection of Main Valve Position VP/VG
Directional Control Valves ? Pilot Operated 3 Port Solenoid Valves
-
?Safety standard ISO 13849-1 certified (Corresponding to category2 to 4)
?With detection of main valve position
?It is possible to construct a redundant system easily
?Highly reliable construction
?Safety limit switch can be selected
?With soft start-up function (-X555)
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Category | Flow rate characteristics 2→3（A→R） C［dm3/（s?bar）］ | Flow rate characteristics 2→3（A→R） b | Flow rate characteristics 2→3（A→R） Cv |
|---|---|---|---|---|
| Residual pressure release valve VP542-X536 Body ported | 2 | 8.9 | 0.20 | 2.1 |
| Residual pressure release valve VP544-X536 Base mounted | 2 | 8.8 | 0.13 | 2.0 |
| Residual pressure release valve VP742-X536 Body ported | 2 | 15.3 | 0.22 | 3.7 |
| Residual pressure release valve VP744-X536 Base mounted | 2 | 15.0 | 0.17 | 3.4 |
| Dual residual pressure release valve VP544-X538 | 3,4 | 6.7 | 0.10 | 1.3 |
| Dual residual pressure release valve VP744-X538 | 3,4 | 9.7 | 0.08 | 2.1 |
| Dual residual pressure release valve with soft start-up function VP544-X555 | 3,4 | 6.7 | 0.10 | 1.3 |
| Dual residual pressure release valve with soft start-up function VP744-X555 | 3,4 | 9.7 | 0.08 | 2.1 |
| Dual residual pressure release valve VG342-X87 | 3,4 | 28.6 | 0.03 | 5.6 |
Modular Connection Type Residual Pressure Relief 3 Port Solenoid Valve VP500/700
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Pressure Relief 3 Port Valves
-
?For connecting to F.R.L. units (AC-A Series)
?Allows for space saving and reduced piping labor
?Power consumption: 0.35 W (Without light)
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Applicable combinations |
|---|---|
| VP500 | AC25-A，AC30-A |
| VP700 | AC40-A |
