Blow Gun VMG
Silencers/Exhaust Cleaners/Blow Guns/Pressure Gauges ? Blow GunsDirectional Control Valves ? Blow Guns
-
?A 20% reduction in power consumption can be achieved with the SMC “Blow gun” + “S coupler” + “Coil tube.”
?Pressure loss: 1% or less (Nozzle size: ?2.5)
?Available nozzles:
Male thread nozzle, High efficiency nozzle with male thread,
Low noise nozzle with male thread, Copper extension nozzle
?With flow rate adjustment function (-X54)
| Series | Port size | Operating pressure range （MPa） | Effective area （mm2） | Nozzle port size |
|---|---|---|---|---|
| VMG | Rc，NPT，G 1/4，3/8 | 0 to 1.0 | 30 | Rc1/4 |
Nozzles for Blowing KN
Silencers/Exhaust Cleaners/Blow Guns/Pressure Gauges ? Blow Guns
-
*Refer to the Operation Manual (VMG) for details on how to mount the copper extension nozzle set.
| Series | Type | Nozzle size |
|---|---|---|
| KN | Nozzle with self-align fitting | ?1 to ?6 |
| KN | Nozzle with male thread | ?1 to ?8 |
| KNL | Copper extension nozzle | ?1.5 to ?3 |
| VMG | Copper extension nozzle set | ?1.5 to ?3.5 |
| KN-Q□A | Nozzle for One-touch fitting (Resin type) | ?1 to ?3 |
| KN-Q□ | Nozzle for One-touch fitting (Metal type) | ?1 to ?3 |
| KNK | Pivoting nozzle with self-align fitting | ?4, ?6 |
| KNK | Pivoting nozzle with male thread | ?4, ?6 |
| KNH | High efficiency nozzle | ?1 to ?2 |
| KNS | Low noise nozzle with self-align fitting | ?0.75 x 4 to ?1 x 4 |
| KNS | Low noise nozzle with male thread | ?0.75 x 4 to ?1.1 x 8 |
| KNP | Standard sensing head | ?2.5 |
| KNP | Needle sensing head | ?0.7 |
| P5670129-□ | Nozzle cover | Refer to the catalog. |
| KN-R03-400-X1484 | Blower nozzle (Made to order) | 4 x 11 (Nozzle port size) |
| KN-06-150-X1567 | Bender tube (Made to order) | ?1.5 |
| KN | Stainless steel nozzle (Made to order) | Refer to the catalog. |
| ZH-X226 ZH-X338 ZH-X249 | Vacuum flow | Refer to the catalog. |
