Hydraulic Cylinders
- Energy Saving
- By Industry ⁄ Process
- Applications
JIS Standard Hydraulic Cylinder CH2/CHD2
Hydraulic Equipment ? Hydraulic Cylinders
-
?Uses a cushion seal type mechanism, Reduces impact at the stroke end, Improves durability
?Rod cover with block construction makes for easy disassembly and assembly
?With auto switch (CHD2 series: CHD2E, CHD2EW, CHD2F, CHD2FW, CHD2G, CHD2H)
Safety Instructions Hydraulic Cylinders/Precautions Auto Switches/Precautions
Series Variations Technical Data Green Procurement (RoHS)
Series Variations Technical Data Green Procurement (RoHS)
| Series | Nominal pressure (MPa) | Tube material | Action | Bore Size (mm) |
|---|---|---|---|---|
| CH2E | 3.5 | Aluminum | Double acting, Single rod | 32, 40, 50, 63, 80, 100 |
| CH2EW | 3.5 | Aluminum | Double acting, Double rod | 32, 40, 50, 63, 80, 100 |
| CH2F | 7 | Stainless steel | Double acting, Single rod | 32, 40, 50, 63, 80, 100 |
| CH2FW | 7 | Stainless steel | Double acting, Double rod | 32, 40, 50, 63, 80, 100 |
| CH2G | 14 | Iron | Double acting, Single rod | 32, 40, 50, 63, 80, 100 |
| CH2H | 14 | Stainless steel | Double acting, Single rod | 32, 40, 50, 63, 80, 100 |
Small Bore Hydraulic Cylinder CHN
Hydraulic Equipment ? Hydraulic Cylinders
-
?Lightweight with a stainless steel tube and aluminum cover
?Uses a cushion seal type mechanism, Reduces impact at the stroke end, Improves durability
?Smaller cover section compared to tie-rod cylinders
Safety Instructions Hydraulic Cylinders/Precautions Auto Switches/Precautions
Series Variations Technical Data Green Procurement (RoHS)
Series Variations Technical Data Green Procurement (RoHS)
| Series | Nominal pressure (MPa) | Tube material | Action | Bore Size (mm) |
|---|---|---|---|---|
| CHN | 7 | Stainless steel | Double acting, Single rod | 20, 25, 32, 40 |
Compact Hydraulic Cylinder CHQ/CHDQ
Hydraulic Equipment ? Hydraulic Cylinders
-
?Lightweight, compact aluminum body
?It is possible to mount auto switches.
?Same longitudinal dimensions for cylinders with/without auto switches
?With auto switch (CHDQ series: CHDQ, CHDQW)
Safety Instructions Hydraulic Cylinders/Precautions Auto Switches/Precautions
Series Variations Technical Data Green Procurement (RoHS)
Series Variations Technical Data Green Procurement (RoHS)
| Series | Nominal pressure (MPa) | Body material | Action | Bore Size (mm) |
|---|---|---|---|---|
| CHQ | 3.5 | Aluminum | Double acting, Single rod | 20, 32, 40, 50 63, 80, 100 |
| CHQW | 3.5 | Aluminum | Double acting, Double rod | 20, 32, 40, 50 63, 80, 100 |
Air-Hydro Booster CQ2
Hydraulic Equipment ? Hydraulic Cylinders
-
?Converts air pressure to hydraulic pressure for high-pressure hydraulic cylinder actuation
?No hydraulic pump is required. High hydraulic pressure can easily be obtained.
?Applications: For lifting workpieces, for automatic clamping devices, hydraulic pressure source for low profile hydraulic cylinders
Safety Instructions Hydraulic Cylinders/Precautionss Auto Switches/Precautions
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Pneumatic cylinder dia. (mm) | Generated hydraulic pressure (with 0.5 MPa) | Amount of discharged oil (cm3) |
|---|---|---|---|
| CQ2 | 100, 140, 160 | 3.5 to 14 | 17 to 105 |
