Pressure Control Equipment
- Energy Saving
- By Industry ⁄ Process
- Applications
Precision Regulator IR1000-A/2000-A/3000-A
Modular F.R.L./Pressure Control Equipment ? RegulatorsPressure Control Equipment ? Regulators
-
?Air consumption: Reduced by up to approx. 90%
(Compared to the existing SMC product)
?High flow rate: Up to approx.
twice that of the existing SMC product
?Lightweight: Reduced by up to approx. 27%
(Compared to the existing SMC product)
?Sensitivity: 0.2% (Full span)
?Repeatability: ±0.5% (Full span)
| Series | Port size | Set pressure (MPa) |
|---|---|---|
| IR1000-A | 1/8 | 0.005 to 0.2 0.01 to 0.4 0.01 to 0.8 |
| IR2000-A | 1/4 | 0.005 to 0.2 0.01 to 0.4 0.01 to 0.8 |
| IR3000-A | 1/4, 3/8, 1/2 | 0.01 to 0.2 0.01 to 0.4 0.01 to 0.8 |
Booster Regulator VBA
Modular F.R.L./Pressure Control Equipment ? Booster RegulatorsBooster Regulators ? Booster Regulators
-
?Can increase factory air by a maximum of 200%, Power supply not required
It is possible to get a maximum of double the existing pressure by connecting the air to a factory line.
(VBA11A: maximum 4 times)
Space-saving type that directly connects air tanks and booster regulators
| Series | Port size | Set pressure (MPa) |
|---|---|---|
| VBA | 1/4，3/8，1/2 | VBA1□A：0.2 to 2.0 VBA2□A：0.2 to 1.0 VBA4□A：0.2 to 1.0 VBA43A：0.2 to 1.6 |
Air Tank VBAT
Air Preparation Equipment ? Aftercoolers/Air TanksModular F.R.L./Pressure Control Equipment ? Booster Regulators
Booster Regulators ? Booster Regulators
-
?Compact air tank that can be directly connected to a regulator
?Can be used as an independent tank
?With a safety valve port (Option)
?Overseas standards compliant products:
CE certified product (-Q)
ASME Standards compliant product (-X105)
Product not applicable to ASME Standards (-X11)
Chinese pressure vessel regulations compliant product (-X104)
Industrial Safety and Health Act KCs Certification compliant product (-X101)
| Series | Port size | Tank capacity (L) |
|---|---|---|
| VBAT | 3/8，1/2，3/4 | 5，10，20，38 |
