Tubing
- Energy Saving
- By Industry ⁄ Process
- Applications
Polyurethane Tubing TU
Fittings and Tubing ? Tubing
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color | Fluid |
|---|---|---|---|---|
| TU/TIUB | φ2，φ4，φ6，φ8 φ10，φ12，φ16 | φ1/8''，φ3/16''，φ1/4'' φ3/8''，φ1/2'' | Black, White, Red, Blue, Yellow, Green, Clear, Orange, and more (Total 29 colors) | Air, Water |
Wear Resistant Tubing TUZ
Fittings and Tubing ? Tubing
-
?Abrasion: Approx. 1/3 (Compared with SMC's TU series polyurethane tubing)
| Series | Tubing O.D. Metric size | Color | Fluid |
|---|---|---|---|
| TUZ | φ4，φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green | Air |
FR Soft Nylon Tubing TRS
Fittings and Tubing ? Tubing(Tubing for Special Environments)
-
?Max. operating pressure: 1.2 MPa (at 20℃)
?For use in spatter-generating atmospheres/Flame resistant
(Equivalent to UL-94 Standard V-0)
Safety Instructions Fittings and Tubing/Precautions Series Variations Improved Weather Resistance Tube Green Procurement (RoHS)
| Series | Tubing O.D. | Color | Fluid |
|---|---|---|---|
| TRS | φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Green | Air, Water |
FR Double Layer Tubing TRB
Fittings and Tubing ? Tubing(Tubing for Special Environments)
-
?Max. operating pressure: 1.0 MPa (at 20℃)
?For use in spatter-generating atmospheres/Flame resistant
(Equivalent to UL-94 Standard V-0)
Safety Instructions Fittings and Tubing/Precautions Series Variations Improved Weather Resistance Tube Green Procurement (RoHS)
| Series | Tubing O.D. | Color | Fluid |
|---|---|---|---|
| TRB | φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green | Air, Water |
FR Double Layer Polyurethane Tubing TRBU
Fittings and Tubing ? Tubing(Tubing for Special Environments)
-
?Max. operating pressure: 0.8 MPa (at 20℃)
?For use in spatter-generating atmospheres/Flame resistant
(Equivalent to UL-94 Standard V-0)
?Superior restoring force compared to the nylon tubing
| Series | Tubing O.D. | Color | Fluid |
|---|---|---|---|
| TRBU | φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green | Air, Water |
FR Three-layer Polyurethane Tubing TRTU
Fittings and Tubing ? Tubing(Tubing for Special Environments)Arc Welding Process Equipment ? Tubing/Fittings/Flow Control Equipment
-
?Spatter resistance has been improved by installing an aluminum layer between the outer layer and the inner tube.
(It is twice that of the TRBU series FR double layer polyurethane tubing.)
?For general pneumatic and water piping in environments exposed to sparks from arc welding, etc.
?Flame resistant (Equivalent to UL-94 Standard V-0)
| Series | Tubing O.D. | Color | Fluid |
|---|---|---|---|
| TRTU | φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green | Air, Water |
Fluoropolymer Tubing TL/TIL
Fittings and Tubing ? Tubing(Fluoropolymer/Clean)
-
?Max. operating pressure: 1.0 MPa (at 20℃)
?Operating temperature (fixed usage): ?65 to 260℃
