Compact 5-Port Solenoid Valve/Plug-in Type JSY1000/3000/5000
Directional Control Valves ? Pilot Operated 4/5 Port Solenoid Valves
-
?Spacer type ejector for JSY1000 with additional high-noise reduction
silencer [New]
?Size reduction has been made possible thanks to a flow increase
This allows for space saving, weight reduction, and a large flow rate.
?Power consumption: 0.1 W (With power-saving circuit), 0.4 W (Standard)
?Connector type manifold
?A 4-position dual 3-port valve is available
?Manifold Type no.: JJ5SY1, JJ5SY3, JJ5SY5
?Can be connected with the ZK2 series vacuum unit
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Flow rate characteristics 4/2→3/5（A/B→E） C［dm3/（s?bar）］ | Flow rate characteristics 4/2→3/5（A/B→E） b | Applicable cylinder size | Power consumption (W) |
|---|---|---|---|---|
| JSY1000 | 0.91 | 0.48 | φ40 | 0.2 (With power-saving circuit) |
| JSY3000 | 2.77 | 0.27 | φ50 | 0.4 (Standard) 0.1 (With power-saving circuit) |
| JSY5000 | 6.59 | 0.22 | φ80 | 0.4 (Standard) 0.1 (With power-saving circuit) |
