Compact Vacuum Pad (Vacuum Suction Cup) ZP3
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Pads (Vacuum Suction Cups)
-
?Overall length shortened
?Pad form: Flat type, Flat type with groove, Bellows type, Bellows type with ribs
?Mounting: Male thread, Female thread
?Vacuum inlet direction: Vertical, Lateral
?Vacuum inlet: Male thread, Female thread, One-touch fitting, Barb fitting
?Buffer: Without, With
[Buffer stroke [mm]: 3, 6, 10, 15, 20]
Safety Instructions Vacuum Equipment/Precautions Vacuum Pads/Precautions Series Variations Model Selection Mounting Bracket Assembly (p.162-164) Green Procurement (RoHS)
| Series | Pad form | Pad diameter(mm) |
|---|---|---|
| ZP3 | Flat type | φ1.5,φ2,φ3.5 |
| ZP3 | Flat type with groove | φ4,φ6,φ8,φ10,φ13,φ16 |
| ZP3 | Bellows type | φ4,φ6,φ8 |
| ZP3 | Bellows type with ribs | φ10,φ13,φ16 |
