Thermo-chiller/Standard Type HRS
Industrial Device Communication Equipment/Wireless System ? Other: RS485 Compatible ProductsIndustrial Device Communication Equipment/Wireless System ? Other: RS232C Compatible Products
Temperature Control Equipment ? Thermo-Chillers (Circulating Fluid Temperature Controllers) Standard Type/Basic Type
-
?With this chiller, cooling water can be obtained anywhere it is necessary because of easy installation and easy operation.
?For a wide range of applications, such as laser machine tools, analytical equipment,
LCD manufacturing equipment, mold temperature control, etc.
?Compact: W 377 x H 615 x D 500 mm, 40 kg (HRS012/018/024)
?Timer function, Low liquid level protection, Power failure auto-restart,
Anti-freezing function, etc.
?Self diagnosis function
?Ideal for overseas models (Single-phase 200 to 230 VAC, Single-phase 100, 115 VAC)
?Compliant with UL Standards, CE-marking
Safety Instructions Temperature Control Equipment/Precautions Features/Series Variations
Technical Data Can be used in a wide range of applications!
Temperature Control Equipment Warranty Green Procurement (RoHS)
Technical Data Can be used in a wide range of applications!
Temperature Control Equipment Warranty Green Procurement (RoHS)
| Series | Set temperature range | Cooling capacity | Temperature stability | Cooling method | Circulating fluid |
|---|---|---|---|---|---|
| HRS012 to 060 | 5 to 40℃ | 1.3 kW 1.9 kW 2.4 kW 3.2 kW 4.2 kW 5.1 kW 5.9 kW （60 Hz） | ±0.1℃ | Air-cooled refrigeration Water-cooled refrigeration | Tap water Deionized water Ethylene glycol aqueous solution （15％） |
Thermo-chiller/Inverter Type HRSH
Industrial Device Communication Equipment/Wireless System ? Other: RS485 Compatible ProductsIndustrial Device Communication Equipment/Wireless System ? Other: RS232C Compatible Products
Temperature Control Equipment ? Thermo-Chillers (Circulating Fluid Temperature Controllers) Inverter Type
-
?Complete with energy-saving triple inverter!
?Outdoor installation, Splashproof type (IPX4)
?Max. ambient temperature: 45℃
?Min. ambient temperature: –20℃ (For the air-cooled type)
?Temperature stability: ±0.1℃ (When a load is stable)
?Space saving and lightweight: 280 kg (25 kW type)
?Compliant with UL Standards, CE-marking
Safety Instructions Temperature Control Equipment/Precautions Features/Series Variations
Technical Data Can be used in a wide range of applications!
Temperature Control Equipment Warranty Green Procurement (RoHS)
Technical Data Can be used in a wide range of applications!
Temperature Control Equipment Warranty Green Procurement (RoHS)
| Series | Set temperature range | Cooling capacity | Temperature stability | Cooling method | Circulating fluid |
|---|---|---|---|---|---|
| HRSH | 5 to 35℃ | 10 kW 15 kW 20 kW 25 kW 28 kW | ±0.1℃ | Air-cooled refrigeration Water-cooled refrigeration | Tap water Deionized water Ethylene glycol aqueous solution (15%) |
Thermo-chiller/Rack Mount Type HRR
Industrial Device Communication Equipment/Wireless System ? Other: RS485 Compatible ProductsIndustrial Device Communication Equipment/Wireless System ? Other: RS232C Compatible Products
Temperature Control Equipment ? Thermo-Chillers (Circulating Fluid Temperature Controllers) Rack Mount Type
-
?Operable without the need to remove the unit from the rack
Front access: Simple to control, service, and maintain with all filters and drainage accessible via the front panel
?Space saving: Multiple chillers can be mounted to a 19-inch rack.
?Cooling capacity: 1.1/1.2/1.8/2.4/3.0/5.1 kW (60 Hz)
?Temperature stability: ±0.1℃
?Global power supply:
Single-phase 100 VAC (50/60 Hz)/115 VAC (60 Hz)
Single-phase 200 to 230 VAC (50/60 Hz)
Safety Instructions Temperature Control Equipment/Precautions Features/Series Variations
Technical Data Temperature Control Equipment Warranty Green Procurement (RoHS)
Technical Data Temperature Control Equipment Warranty Green Procurement (RoHS)
| Series | Set temperature range | Cooling capacity | Temperature stability | Cooling method | Circulating fluid |
|---|---|---|---|---|---|
| HRR | 5 to 35℃ 15 to 35℃ | 1.1 kW 1.2 kW 1.8 kW 2.4 kW 3.0 kW 5.1 kW | ±0.1℃ | Air-cooled refrigeration Water-cooled refrigeration | Tap water Ethylene glycol aqueous solution (15%) |
