|8. Cutting ? Rolling
While continuing to unroll, the film is cut down the middle direction and rolled up at a constant level of tension.
Tension Control
| Use | Item name | Series |
|---|---|---|
| Low-friction control-related equipment |
Low Friction Cylinder (Metal seal type) | MQQ / MQM / MQP |
| Smooth Cylinder | CJ2Y / CM2Y / MBY CA2Y / CS2Y / CQ2Y |
|
| Electro-pneumatic Regulator | ITV0000 / 1000 / 2000 3000 |
|
| Precision Regulator | IR1000 / 2000 / 3000 |
Preventing Attachment of Foreign Objects ? Quality Improvement
| Use | Item name | Series |
|---|---|---|
| Anti-static electricity measures |
Ionizer | IZS 40 / 41 / 42 |
| Clean blow | Clean Air Module | LLB |
| Direct Operated 2 Port Solenoid Valve | VX2 | |
| Clean One-touch Fittings (for Blowing) | KP | |
| Polyolefin Tubing | TPH | |
| Soft Polyolefin Tubing | TPS |
Clean Room Specifications
| Use | Item name | Series |
|---|---|---|
| Pneumatic equipment for clean room |
Clean Series | Clean Series |
Quality Improvement
| Use | Item name | Series |
|---|---|---|
| Non-contact pad | ---- | XT661 |
Points and Precautions for Selection
? A low slide-resistance cylinder and a high-precision pressure control are necessary for tension control.
Please use in combination with a low-friction type cylinder, precision regulator and electro-pneumatic regulator.
? When selecting a cylinder for cutting, please choose a high-rigidity, high-precision cylinder with a guide.
? For better product performance, please use air preparation equipment to improve the quality of the air.
? When using in a clean environment, please select equipment that conforms to clean-room class standards of cleanliness.
