|1. Dissolution of Raw Materials
Dried chips of raw material (PET) are
fed into a hopper, then supplied to an
extruder and completely melted down.
Blending of Raw Materials
| Use | Item name | Series |
|---|---|---|
| Explosion-proof equipment | Intrinsically Safe Explosion-proof System 5 Port Solenoid Valve | 51-SY |
| *5 Port Solenoid Valve | SY | |
| *5 Port Solenoid Valve | VQC | |
| Industrial Filters | Industrial Filter | FG |
* Does not meet explosion-proof specifications. Please use only in non-explosion proof areas.
Solvent Atmosphere
| Use | Item name | Series |
|---|---|---|
| Improved corrosion resistance | Stainless Steel Cylinder | CJ5?S / CG5?S |
| Floating Joint (Stainless Steel) | JS | |
| Stainless Steel 316 One-touch Fittings | KQG | |
| Stainless Steel 316 Insert Fittings | KFG | |
| FEP Tubing | TH / TIH | |
| Fluororesin Tubing | TL / TIL | |
| Clean Regulator | SRH |
Air-conditioning Duct Control / Raw Material Quantity Control
| Use | Item name | Series |
|---|---|---|
| Duct opening control Valve opening control Instrumentation system |
Electro-Pneumatic Positioner | IP8000 / 8100 |
| Precision Regulator | IR1000 / 2000 / 3000 |
Points and Precautions for Selection
? When using in an explosion-proof area, please select explosion-proof equipment.
? Please use a low-power-consumption solenoid valve if you plan to keep the solenoid valve energized for extended periods
of time. Please refer to page 26 for details.
? Using equipment in a solvent atmosphere may result in diminished product quality, so please check the specifications and
materials of the model.
? When using equipment at high temperatures or in a solvent atmosphere, please check the specifications (operating temperature,
materials, etc.) of the model before using.
